VDP2D-I-4TGX

VDP2D-I-4TGX is a VDSL2 port with 4 x10/100/1000Mbps ethernet ports.

That provide an end to end  solution for industrial applications.

VDP2D-I-4TGX support high bandwidth up to 160Mbps symmetric and long reach transmission up to 3km, and also supports both Master and Slave modes selectable by DIP Switch.

VDP2D-I-4TGX’s DIN-Rail and Power redundancy features offer quick, easy, safety wide range and high performance broadband / Triper play services to industrial environments such as Factory, MRT, Train station, Ticket vending machine, Parking system, Weather station, Military Training system, Monitoring system, Farm, Jail, Refinery, Passenger ship...

  • Supports high bandwidth up to 160Mbps symmetric over Line ports
  • Support long reach transmission up to 3 km with 24 gauge phone wire
  • Support auto speed and 8 profiles mode selectable by DIP switch
  • Master and Slave mode selectable by DIP switch
  • Supports Jumbo frame up to 2k bytes
  • Built in Surge protector
  • Supports Overload Current Protection
  • Supports wide range operating temperature(-20°C~ 70°C )
  • Supports Reverse Polarity Protection
  • Supports alarm contact (relay output - 1 A @ 24 VDC)
  • Supports DIN-Rail mount installation
  • Metal case design and compliant with IP30 standard
  • Support power redundant and wide range dual power input(DC15V ~ 48V)





Standard

IEEE802.3/802.3u/802.3ab Ethernet standard

G993.2 VDSL2 standards

Physical Interface

4 * RJ45 10/100/1000Mbps Ethernet port

1 * RJ11/Terminal Block connector for VDSL2 line port

1 * DIP Switch

1* Removable 6-contact terminal blocks for Power1 and alarm contact

1* Removable 2-contact terminal block for Power2

LED Indicators

1 * Power LED

4 * Link/Active Status for Ethernet port

1 * Link/Speed LED for VDSL2 port

1 * CO Mode indicator LED

1 * CPE Mode indicator LED

VDSL2 Line Code

DMT modulation

VDSl2 Transmission Code

Packet Transfer Mode (PTM)

Typical Power consumption

6W

Power Input

Input Voltage: 15V to 48VDC

Input Current: 0.5A or above

Dimensions

171 * 121 * 35 mm (6.7’’ * 4.76’’ * 1.37’’)

EMC

EMI Compliant: FCC class A

EMS Complaint: CE mark

Temperature

-20°~ 70° C (Operating), -40°~70°C (Storage)

Fanless, free air cooling

Humidity

5 to 95% non-condensing

VDP2D-I-4TGX

Industrial 4 VDSL2 PTM modem 2 wire, 100/100Mbps at 300m , 5/1 at 3km, selection as CO/CPE or master/slave per DIP switch, 4 x 10/100/1000BT ports, VLAN transparent. Power input 15~48VDC
